DMTA-10045-01EN, Rev. E, August 2016
Control Functions
97
For DWELL and HORN parameter adjustment details, see “PC RF Mode — ALARM
Menu in RF RUN” on page 93. Parameter descriptions are based on the presumption
that the BondMaster 600 is set to PC Swept mode and the ALARM menu key ( )
has been pressed.
SPEC ALM
The SPEC ALM (spectrum alarm) enables the alarm from the SPECTRUM RUN,
and you can configure it as positive or negative.
To change the SPEC ALM, press the A key, and then rotate the knob to the
desired setting.
XY ALM 1 (XY alarm 1)
The XY ALM 1 (XY alarm 1) setting controls the XY 1 alarm type and can be set to
OFF, POS (frequency positive), or NEG (frequency negative).
To change the XY alarm 1 type, press the B key, and then rotate the knob to the
desired type.
XY ALM 2 (XY alarm 2)
The XY ALM 2 (XY alarm 2) setting controls the XY 2 alarm type and can be set to
OFF, POS (frequency positive), or NEG (frequency negative).
To change the XY alarm 2 type, press the C key, and then rotate the knob to the
desired type.
PC Swept mode’s DWELL and HORN examples are shown in Figure 5-14 on page 98
and Figure 5-15 on page 98.
