DMTA-10045-01EN, Rev. E, August 2016
Chapter 5 72
DISP/DOTS ( )
Provides access to the display menu, which controls functions such as display
mode, position, trace, and grid.
ALARM ( )
Provides access to the alarm menu, which controls functions such as alarm type,
dwell time, horn volume, and alarm position.
MEM ( )
Provides access to the memory menu, which controls functions such as
previewing stored memory files, recalling and editing stored files, capture mode,
capture time, and user information.
ADV SETUP ( )
Provides access to the ALL SETTINGS setup menu which controls
BondMaster 600 setup parameters such as frequency mode, colors, password,
unlock options, and reset. This menu displays all BondMaster 600 settings at the
same time.
5.2.5 SmartKnob
This rotating knob, called the SmartKnob, is located in the upper left-hand side of the
BondMaster 600. Its primary purpose is to adjust the selected BondMaster 600
parameter. When the box of the parameter being adjusted is highlighted, rotating the
knob clockwise increases the value and rotating it counterclockwise decreases the
value. In some cases, the knob may also be used to respond to various prompts from
the BondMaster 600.
5.2.6 Hidden Function — Screen Capture
On the BondMaster 600 instrument, you can send a screen-capture image file to the
removable (external) microSD card by holding the MAIN menu key ( ), and then
pressing the REF SAVE key ( ). Alternatively, you can use the BondMaster PC
software to capture a screen image (see “Screen Capture Using BondMaster PC” on
page 173).
