DMTA-10045-01EN, Rev. E, August 2016
Chapter 7
198
To delete a file on the BondMaster 600
1. In the Manage File dialog box, choose the file to be deleted, and then click Delete
(see Figure 7-17 on page 197).
The Confirmation dialog box appears, asking you to confirm that you want to
delete the file on the device (see Figure 7-18 on page 198).
2. Click Yes to confirm file deletion.
OR
Click No to cancel the file deletion.
If you click Yes to confirm file deletion in the Confirmation dialog box, the file is
permanently deleted, and it cannot be retrieved.
Figure 7‑18 The Confirmation dialog box for file deletion
To rename a file on the BondMaster 600
1. In the Manage File dialog box, choose the file to be renamed, and then click
Rename (see Figure 7-17 on page 197).
The Rename dialog box opens (see Figure 7-19 on page 199).
