DMTA-10045-01EN, Rev. E, August 2016
Specifications
215
Table 13 Pitch‑catch tone burst and swept mode specifications
Category Parameter Va lu e
Pitch-catch tone burstDisplay modes (RUN
key)
Choice of RF view (time-based
waveform featuring raw waveform
named RF, or signal amplitude
envelope named IMPULSE), single
impedance plane (also named XY
flying dot), split screen (RF and XY),
strip chart (named SCAN, representing
amplitude and phase against time),
split screen (XY + SCAN)
Frequency range 1 kHz to 50 kHz
Gain RF waveform gain (raw signal): 0 dB to
70 dB, adjustable in 0.1 dB or 1 dB
increments. An additional 0 dB to
60 dB is available for the XY flying dot
display.
Width
360 μs to 10 ms, adjustable in 50 μs
increments
Gate 10 μs to 7920 μs, adjustable in 10 μs
steps. New AUTO gate mode that
auto-detects the peak amplitude from
RF signal.
Cycles 1 to 10, adjustable in 1 cycle increments
Repetition rate 5 to 500 repetitions per second,
adjustable in 5 rep/s increments
Dot recordings Up to 25 user-defined dot recordings
