Olympus BondMaster 600 - Changing the Display Settings; Changing the Display Brightness

DMTA-10045-01EN, Rev. E, August 2016
Initial Setup 65
a) Press the FULL NEXT key ( ) until the item (YEAR, MONTH, DAY etc.) is
highlighted.
b) Rotate the knob until the correct value is displayed.
3. Press to return to the main inspection screen.
4.3 Changing the Display Settings
You can change the appearance of some display elements such as brightness, auto
erase, VGA output, and the application window (or screen) at startup.
To change the display settings
1. Press the ADV SETUP menu key ( ) twice.
2. Press the B key to access the SYSTEM SETUP screen.
3. In the SYSTEMS SETUP screen (see Figure 4-1 on page 64), use the FULL NEXT
key ( ) to highlight the desired parameter and then use the knob to change its
value:
a) Set BRIGHTNESS to one of the predefined brightness levels: 0%, 25 %, 50 %,
75 %, or 100 % (see “Changing the Display Brightness” on page 65 for more
details on brightness).
b) Set VGA OUTPUT to ON or OFF.
c) Set AUTO ERASE to ON or OFF (see “Adjusting Auto Erase” on page 66 for
details).
d) Set APPLICATION WINDOW AT STARTUP to ON or OFF (see “Selecting
the Startup Screen” on page 67 for more details).
4. Press to return to the main inspection screen.
4.4 Changing the Display Brightness
You can adjust the BondMaster 600 display brightness by changing the backlight
intensity. The display brightness can be set at 0 %, 25 %, 50 %, 75 %, or 100 %.
Choosing a high percentage increases the brightness of the display. By default, the
