Olympus BondMaster 600 - Figure 2-3 the Connectors Behind the I;O Door

DMTA-10045-01EN, Rev. E, August 2016
Overview of the BondMaster 600 27
Figure 2‑3 The connectors behind the I/O door
The I/O and the VGA OUT connectors are located at the back of the BondMaster 600,
in the upper section (see Figure 2-4 on page 28). A rubber cover protects each
connector.
USB port
microSD card slot
I/O door
microSD card
