If the BondMaster 600 is being used in noisy conditions, an external horn can be used.
The horn connects to the I/O connector on the back of the BondMaster 600 and
increases the audible alarm’s sound output to 70 dB (see Table 8 on page 209 for the
part specification).
3.4 Displaying Real-Time Readings
The real-time readings bar displays user-configurable readings (measurements) [see
Figure 3-5 on page 55]. It can display a maximum of two real-time readings from
among the available choices—the number of available choices depends on the
selected operating mode. The real-time readings bar can be set to display one or two
readings, or it can be disabled.
The real-time readings bar can display the following readings (see Figure 3-7 on
page 59 and Figure 3-8 on page 59):
• LIVE AMPL — Maximum distance between current XY (horizontal, vertical) dot
position (swept mode excluded) and null position.
• LIVE VERT — Maximum distance between current vertical (Y) dot position
(swept mode excluded) and null position.
• LIVE HORZ — Maximum distance between current horizontal (X) dot position
(swept mode excluded) and null position.
• LIVE ANGL — Angle of current XY position with respect to the null point (swept
mode excluded).
• AMPLITUDE P‑P — Volts peak-to-peak or largest signal (swept mode only).
NOTE
