Olympus BondMaster 600 - Changing CIRCLE Alarm Parameters in PC Swept Mode

DMTA-10045-01EN, Rev. E, August 2016
Control Functions 91
•RUN
•CURSOR
•GRID
•D ERASE
•RECORD
For details on RUN, CURSOR, GRID, and D ERASE parameter adjustments, see “PC
RF Mode — DISP/DOTS Menu” on page 84. Parameter descriptions are based on the
presumption that the BondMaster 600 is set to PC Swept mode and the DISP/DOTS
menu key ( ) has been pressed.
RECORD
The RECORD setting enable you to display frequency-tracking signal traces (up
to two traces) during a RUN that uses the XY display.
To change the RECORD setting, press the DISP/DOTS menu key ( ) twice,
then press the E key, and then rotate the knob to adjust the setting.
5.3.7 MIA Mode — DISP/DOTS Menu
The following parameters can be adjusted on the MIA Mode DISP/DOTS
(display/dots) menu:
•RUN
• POSITION
• H POS (horizontal position)
• V POS (vertical position)
• STORE NEXT
•RE‑WRITE DOT
• ERASE DOT
• ERASE ALL
•SET REF
• D ERASE (display erase)
• PERSIST
NOTE
