DMTA-10045-01EN, Rev. E, August 2016
Specifications
211
A.2 Input/Output Specifications
Table 9 on page 212 provides the specifications for the input and output signals.
Display Size (width × height,
diagonal)
117.4 mm × 88.7 mm, 146.3 mm (4.62 in. × 3.49 in.,
5.76 in.)
Resolution 640 × 480 pixels (full VGA)
Number of colors 256
Type Full VGA (640 × 480 pixels) color transflective LCD
(liquid crystal display)
Viewing angles Horizontal: −80° to 80°
Vertical: −80° to 80°
Screen modes Normal or full screen
Grid and display tools Choice of 5 grids (OFF, 10 × 10, FINE, COARSE,
and WEB) and user-selected crosshairs available on
XY displays
Modes (all possible) Available display modes depend on the
BondMaster 600 model and selected operating
mode. Choice of RF view (time-based waveform
featuring raw waveform named RF, or signal
amplitude envelope named IMPULSE), single
impedance plane (also named XY flying dot), split
screen (RF and XY), strip chart (named SCAN,
representing amplitude and phase against time),
split screen (XY + SCAN), SPECTRUM (amplitude
and phase against frequency) and split screen (XY +
SPECTRUM).
Other Standards or directives MIL Standard 810G, CE, WEEE, FCC (USA), IC
(Canada), RoHS (China), RCM (Australia and New
Zealand), KCC (Korea)
Power requirements AC mains: 100 VAC to 120 VAC, or 200 VAC to
240 VAC, 50 Hz to 60 Hz
Warranty One year limited; extra warranty year available for
purchase (W2-BONDMASTER600 [U8775337])
Table 8 General and environmental specifications (continued)
Category Parameter Va lue
