7.6 Remote Control
The BondMaster PC software allows you to remotely control the BondMaster 600.
This is especially useful if the instrument is being used in hot cell areas (shielded
nuclear radiation containment chambers) or for training purposes.
You can enable the BondMaster PC software’s remote control function by clicking
Remote Control in the Device menu (see Figure 7-12 on page 180). The software’s
Remote Command dialog box will then display an image of the front face of the
BondMaster 600, including its control buttons and display. You can then control the
instrument in the same way as you would if it were in front of you (see Figure 7-14 on
page 195).
To display the instrument screen, you must first click Refresh Screen in the Remote
Command dialog box (see Figure 7-14 on page 195). For simultaneous setting
verification, use the BondMaster 600 display or an external monitor.
