l Execute a tap sequence on the touch screen during the power-up phase. A tap sequence is a high frequency
sequence of touch activations executed immediately after the device has been powered.
l From the System Setting page in User Mode, restart the panel in Configuration OS mode
Elements available in User Mode
Element Description
Calibrate Touch Calibrate the touch screen
Display settings Control backlight inactivity timeout and brightness
Time Set HMI device date and time manually or configure NTP servers
Regional Settings Select or customize the regional setting parameters
BSP Settings Display operating system version and unit operating timers to control buzzer and battery led.
Network Sets IP address and other network settings
Plug-in List List the plug-in modules installed and recognized by the system.
Note: this option may not be supported by all platforms and all versions.
Close Closes the system setting page
Restart Restart the HMI device
l Main OS
Restart the HMI device in the operating mode
l Configuration OS
Restart the HIM device with System Setting tool active in System Mode
Elements available in System Mode
In addition to those available in User Mode, the following features are also available:
Element Description
Format Flash Formats the internal device flash disk. All projects and the HMI Runtime will be
erased, returning the device to its factory settings.
Restore Factory Settings Restores factory settings as an alternative to Format Flash, in a more flexible
way. The following options are available:
Uninstall HMI: removes the HMI Runtime (entire qthmi folder) at the next start
the device will behave as a brand new unit. This command does not reset settings
such as IP address, brightness or RTC.
Clear System Settings: resets system parameters (registry settings) and
deletes the following files:
\\Flash\\Documents and Settings\\system.hv
382
HMWIN Studio |User Manual|v206 (2017-06-30) |EN|© 2014-2017 Panasonic Electric Works Europe AG
WinCE Devices
