Element Description
\\Flash\\Documents and Settings\\default\\user.hv
\\Flash\\Documents and Settings\\default.mky
\\Flash\\Documents and Settings\\default.vol
System Mode password is also reset.
Clear Controller Application: clears current folders used by CODESYS V2.3
and CODESYS V3 internal controllers for applications:
l \Flash\QtHmi\RTS\APP\*.*
l \Flash\QtHmi\RTS\VISU\*.*
l \Flash\QtHmi\codesys\*
l \Flash\$SysData$\codesys\*
Clear sysdata settings: clears \Flash\$SysData$folder
Service call: To be used only by technical support to fix display
problems.
Note: Not all these options are available for all HMI devices and BSPs.
Resize Image Area Resizes the flash memory reserved to store the splash screen image displayed at
power up. Default settings are normally suitable for all units.
Download Configuration OS Checks and upgrades the current version of the operating system used in System
Mode
Download Main OS Checks and upgrades the current version of the main operating system
Download Splash Image Loads a new file for the splash screen image displayed by the unit at power up.
Tip: Update the splash screen image directly from the HMWIN Studio
programming software.
See "Update of system components from the application" on page418 for details.
Download Bootloader Checks and upgrades the current version of the system boot loader.
Download Main FPGA Checks and upgrades the current version of the main FPGA file. This function
may not be available for all platforms and versions.
Download Safe FPGA Checks and upgrades the current version of the backup copy of the FPGA file.
This function may not be available for all platforms and versions.
HMWIN Studio |User Manual| v206 (2017-06-30) | EN| © 2014-2017 Panasonic Electric Works Europe AG
383
37 System Settings
