Grid Properties
Parameter Description
Enable Enable the grid layout.
A grid will be generate around the widgets of the group
Num rows
Num columns
Number of rows and columns of the grids.
Rows and columns can be removed only if their cells are
empty .
Horizontal overflow
Vertical overflow
This parameter define the behavior of the grid when it is too small
to contain all rows and columns.
l Hidden
Rows and columns that do not fit into the grid are not
displayed
l Visible
The grid can not be made smaller than the minimum size
required to contain all defined rows and columns
l Scroll
When the grid is too small to hold all the defined rows and
columns, the scroll bars can be used to shift the content of
the grid.
42
HMWIN Studio |User Manual|v206 (2017-06-30) |EN|© 2014-2017 Panasonic Electric Works Europe AG
Grouping widgets
