iTN2100 (P100R002) Hardware Description
11 Clock card
Raisecom Technology Co., Ltd.
74
11.1.3 Interfaces
Interface types
There are six interfaces on the iTN2100-TSU panel, as listed in Table 11-1.
Table 11-1 Interfaces on the iTN2100-TSU panel
Interface
Type
Description
2048 KHz or 2048
Kbit/s
(1–2)
RJ45

Supports two 2048 Kbit/s or 2048 KHz external
synchronization interfaces (120Ω balanced
interfaces).

Support protection, electrical level change, and
impedance matching of external clock signals.

Support SSM signal processing and clock
recovery of 2 Mbit/s signals.

Support 2 MHz and 2 Mbit/s signal templates
that meet the G.703 requirements.
1PPS+TOD(I/O)
(1–2)
RJ45

Support two 1PPS+TOD interfaces for
configuring time signal input and output.

One 1PPS+TOD electrical level support RS422
only and the other 1PPS+TOD electrical level
supports RS422 and RS232.

When 1PPS+TOD electrical level is set to
RS232, it needs to cooperate with the APPS
interface. It means that the 1PPS+TOD
interface transmits TOD information only and
supports translating different forms of TOD.
1PPS(I/O)
BNC

Support one 1PPS interface for configuring
time signal input and output.

Support translating different forms of TOD.

Support TTL electrical level.
–
Mini USB
Debugging interface used for card software
upgrade debugging
Line order of interfaces
Table 11-2 Line order of 2-way RJ45 interfaces transmitting 2 MHz or 2 Mbit/s clock signals
PIN
Signal definition
1
TX_P
2
TX_N
3
NC
4
RX_P
5
RX_N
6
NC
