Raisecom
iTN2100 (P100R002) Hardware Description
10 Ethernet access cards
Raisecom Technology Co., Ltd.
56
Module
Wavelength
(nm)
Laser
Connec
tor
Tx power
(dBm)
Min.
overload
(dBm)
Extinc
tion
ratio
(dB)
Rx
sensitivit
y (dBm)
Transmi
ssion
distance
(Km)
TSFP-Gb/DS14-3
1490(DFB)
PIN
-10 to -3
-3
9
-21
15
Raisecom TSFP is called as Compact SFP (CSFP) in the industry. To differ from
Raisecom CWDM SFP (CSFP) and highlight the feature of 2 channels, Raisecom
names all Compact SFP as TSFP.
10.1.4 LEDs
There are 19 LEDs on the iTN2100-16GF panel, as listed in Table 10-4.
Table 10-4 LEDs on the iTN2100-16GF panel
LED
Status
Description
PWR
Green
Power LED
Green: the power supply is normal.
Off: the power supply is abnormal.
SYS
Green
System status LED
Green: the system is working improperly.
Off: the system is working improperly.
Blinking green: the system is working properly.
LNK/ACT
(116)
Green
SFP optical interface working LED
Green: SFP optical interfaces 116 are properly connected.
Off: SFP optical interfaces 116 are connected or
disconnected.
Blinking green: SFP optical interfaces 116 are receiving or
sending data.
1000M
Green
SFP optical interface 1000 Mbit/s LED
Green: the Ethernet rate is 1000 Mbit/s.
Off: the Ethernet rate is 100 Mbit/s or the connection fails.
10.1.5 Specifications
Table 10-5 lists specifications of the iTN2100-16GF.
Table 10-5 Specifications of the iTN2100-16GF
Parameter
Value
Dimensions
25 mm (width) × 232 mm (depth) × 240 mm (height)
