Raisecom iTN2100 User Manual

Raisecom
iTN2100 (P100R002) Hardware Description
13 EOP cards
Raisecom Technology Co., Ltd.
98
13.5.3 Interfaces
Interface types
There are eight interfaces on the OPCOM3500E-EOP-FEE1×8 panel, as listed in Table 13-21.
Table 13-21 Interface on the OPCOM3500E-EOP-FEE1×8
Interface
Type
Description
–
RJ45 electrical interface
100BASE-TX interface
Interface parameters
Table 13-22 lists parameters of eight RJ45 interfaces on the OPCOM3500E-EOP-FEE1×8.
Table 13-22 Parameters of eight RJ45 interfaces on the OPCOM3500E-EOP-FEE1×8
Parameter
Description
Connector type
RJ45
Interface rate
100Base-TX, support auto-negotiation (in this situation, it
supports 100 Mbit/s full duplex only)
Line code
4B/5B block coding, MLT-3 Line code
Duplex mode
Full duplex
Flow control
IEEE 802.3x-based flow control in full duplex mode
Line order
Auto MDI/MDIX
Compliance standard
IEEE 802.3u
13.5.4 LEDs
There are 10 LEDs on the OPCOM3500E-EOP-FEE1×8 panel, as listed in Table 13-23.
Table 13-23 LEDs on the OPCOM3500E-EOP-FEE1×8 panel
Interface
Status
Description
PWR
Green
Power LED

Green: the power supply is normal.

Off: the power supply is abnormal.
SYS
Green
System status LED

Green: the system is working improperly.

Off: the system is working improperly.

Blinking green: the system is working properly.
