Table 20-8 describes configurations on DIP switches of the iTN2100-Gb (B).
Table 20-8 Configurations on client-side interfaces of the iTN2100-Gb (B)
Client-side
signal
SFP module
DIP
switch
Configuration
Recommended
configuration
STM-16
Optical signal
USFP-48 series SFP optical
modules
FFFNFFFF
2R mode
–
FFFFNFFN
3R mode + manual +
STM-16
Recommended
Better jitter
performance
STM-4
Optical signal

USFP-48 series SFP optical
modules

USFP-Gb series SFP optical
modules
FFFNFFFF
2R mode
–
FFFFNFNF
3R mode + manual +
STM-4
Recommended
Better jitter
performance
STM-1
Optical signal

USFP-48 series SFP optical
modules

USFP-Gb series SFP optical
modules
FFFNFFFF
2R mode
–
FFFFNFNN
33R mode + manual +
STM-1
Recommended
Better jitter
performance
1000BASE-X
Optical signal

USFP-48 series SFP optical
modules

USFP-Gb series SFP optical
modules
FFFNFFFF
2R mode
Recommended
FFFFNFFF
3R mode + manual +
GE
Better jitter
performance
100BASE-X
Optical signal

USFP-48 series SFP optical
modules

USFP-Gb series SFP optical
modules
FFFNFFFF
2R mode
Recommended
FFFFNNFF
3R mode + manual +
FE
Better jitter
performance
1000BASE-T
Electrical
signal

USFP-GE series SFP electrical
modules

USFP-GE/AN series SFP
electrical modules
FFFNFFFF
2R mode
Recommended
FFFFNFFF
3R mode + manual +
GE
Better jitter
performance
100BASE-T
Electrical
signal
USFP-GE/AN series SFP
electrical modules
FFFNFFFF
2R mode
Recommended
FFFFNFFF
3R mode + manual +
GE
Better jitter
performance
USFP-FE/AN series SFP
electrical modules
FFFNFFFF
2R mode
Recommended
FFFFNNFF
3R mode + manual +
FE
Better jitter
performance
10BASE-T
Electrical
signal
USFP-GE/AN series SFP
electrical modules
FFFNFFFF
2R mode
Recommended
FFFFNFFF
3R mode + manual +
GE
Better jitter
performance
USFP-FE/AN series SFP
electrical modules
FFFNFFFF
2R mode
Recommended
