iTN2100 (P100R002) Hardware Description
15 PDH and RCMS cards
Raisecom Technology Co., Ltd.
166
DIP
switch
Function
Status
Description
Bit1
Bit2
Bit3
Bit4
Optical interface
device
ON
OFF
ON
ON
SS13
ON
OFF
ON
OFF
SS15
ON
OFF
OFF
ON
SS23
ON
OFF
OFF
OFF
SS25
SW2 is properly configured before the card leaves the factory. Do not configure it if
not needed.
Table 15-37 Configurations of DIP switch SW3 on the OPCOM3500E-120FE×4-GE
SW3
Function
Status
Description
Description
DIP
bit
Bit1
Enable or
disable auto-
negotiation
on an
Ethernet
interface.
ON
Disable auto-negotiation on
an Ethernet interface.
–
OFF
Enable auto-negotiation on
an Ethernet interface.
Bit2
Configure
Ethernet
interface rate.
ON
Set the Ethernet interface
rate to 10 Mbit/s.

This bit is valid when
auto-negotiation is
disabled.

This bit is invalid when
auto-negotiation is
enabled.
OFF
Set the Ethernet interface
rate to 100 Mbit/s.
Bit3
Set Ethernet
interface
duplex mode.
ON
Set the Ethernet interface to
half duplex mode.

This bit is valid when
auto-negotiation is
disabled.

This bit is invalid when
auto-negotiation is
enabled.
OFF
Set the Ethernet interface to
full duplex mode.
Bit4
Enable or
disable ALS
on the optical
interface.
ON
Enable ALS.
–
OFF
Disable ALS.
Bit5
Reserved
–
–
–
Bit6
Bit7
