Raisecom
iTN2100 (P100R002) Hardware Description
10 Ethernet access cards
Raisecom Technology Co., Ltd.
60
Optical
interface
Connector
Working
wavelength
(nm)
Transmit
power
(dB)
Receiver
sensitivity
(dBm)
Light
saturation
(dB)
Transmission
distance (km)
Optical
loss
(dB/km)
SS15
SC/PC
Tx: 1550
Rx: 1310
-12 to -3
-30
-8
025
0.25
SS23
SC/PC
Tx: 1310
Rx: 1550
-5 to 0
-32
-8
1050
0.5
SS25
SC/PC
Tx:1550
Rx:1310
-5 to 0
-32
-8
1050
0.25
The transmission distance in Table 10-8 is the maximum transmission distance in
typical fiber conditions. The actual transmission distance depends on the network.
10.2.4 LEDs
There are 10 LEDs on the iTN2100-8FX panel, as listed in Table 10-9.
Table 10-9 LEDs on the iTN2100-8FX panel
LED
Status
Description
PWR
Green
Power LED
Green: the power supply is normal.
Off: the power supply is abnormal.
SYS
Green
System status LED
Green: the system is working improperly.
Off: the system is working improperly.
Blinking green: the system is working properly.
LNK/ACT
(18)
Green
SFP optical interface working LED
Green: SFP optical interfaces 18 are properly
connected.
Off: SFP optical interfaces 18 are connected or
disconnected.
Blinking green: SFP optical interfaces 18 are receiving
or sending data.
10.2.5 Specifications
Table 10-10 lists specifications of the iTN2100-8FX.
