Raisecom
iTN2100 (P100R002) Hardware Description
14 EOS cards
Raisecom Technology Co., Ltd.
126
DIP
switch
Function
Status
Description
Bit1
Bit2
Bit3
Bit4
Optical interface
device
ON
OFF
OFF
OFF
SS25
SW2 is properly configured before the card leaves the factory. Do not configure it if
not needed.
14.3.6 Alarms
Table 14-15 lists alarms of the OPCOM3500E-4EOS-4FX.
Table 14-15 Alarms of the OPCOM3500E-4EOS-4FX
Alarm
Cause
Level
Alarm overall alarm
TU-AIS, TU-LOP
Critical
Optical signal LOS
No optical signals are input.
Critical
Ethernet optical interface
link failure alarm
Fiber is disconnected.
The RX and TX of the remote device fail.
Critical
EOS AIS alarm
Services are improperly configured.
The channel to the peer device fails.
The cross connection module fails.
Minor
EOS LOP alarm
The interface between a tributary card and
the cross connection card fails.
Services are improperly configured.
Hardware fails.
Critical
Remote device LPR alarm
The remote transceiver is powered off.
Critical
14.3.7 Specifications
Table 14-16 lists specifications of the OPCOM3500E-4EOS-4FX.
Table 14-16 Specifications of the OPCOM3500E-4EOS-4FX
Parameter
Value
Dimensions
25 mm (width) × 232 mm (depth) × 240 mm (height)
Weight
0.4 kg
Max. power consumption
12 W
