Raisecom
iTN2100 (P100R002) Hardware Description
20 Service aggregation cards
Raisecom Technology Co., Ltd.
236
20.2.5 Specifications
Table 20-16 lists specifications of the iTN2100-8SU-S.
Table 20-16 Specifications of the iTN2100-8SU-S
Parameter
Value
Dimensions
25 mm (width) × 232 mm (depth) × 240 mm (height)
Weight
0.44 kg
Max. power consumption
5 W
20.2.6 Optical performance metrics
Table 20-17 lists optical performance metrics of the iTN2100-8SU-S.
Table 20-17 Optical performance metrics of the iTN2100-8SU-S
Parameter
Metric
Central wavelength (nm)
1471, 1491, 1511, 1531, 1551, 1571,
1591, 1611
Passband (nm)
±6.5
Optical connector
SC/PC
Channel insertion loss (dB)
(with the connector)
< 3
Adjacent channel isolation (dB)
> 25
Non-adjacent channel isolation (dB)
> 35
Fiber
9/125 µm single-mode fiber
Return loss (dB)
> 45
Directivity (dB)
> 55
Operating temperature of optical module (°C)
-5 to 65
Storage temperature of optical module (°C)
-40 to 85
20.2.7 Networking applications
The iTN2100-8SU-S card can cooperate with Raisecom iTN2100 series devices to form a
point-to-point, point-to-multipoint, link-like, or ring network topology, meeting networking
requirements of multiple telecommunication networks. The iTN2100-8SU-S card also can
cooperate with Raisecom RCVS1000 series devices to transmit great-capacity video signals,
audio signals, unidirectional and bidirectional data signals, and Ethernet data services through
a fiber simultaneously.
