Raisecom iTN2100 User Manual

Raisecom
iTN2100 (P100R002) Hardware Description
15 PDH and RCMS cards
Raisecom Technology Co., Ltd.
191
Interface
Alarm
Cause
Level
DMO
alarm

No output transmitted signals.
Minor
LCV alarm

Codes of received signals conflict.
Minor
E3 AIS
alarm

Timeslot of the backplane of VC12
corresponding to the local E1 is faulty or
improperly configured.

The E1 channel of the remote PDH device is
faulty or improperly configured.
Minor
15.12.7 Cables
Table 15-74 lists cables of the OPCOM3500E-3DS3/E3.
Table 15-74 Cables of the OPCOM3500E-3DS3/E3
Card
Cable
OPCOM3500E-3DS3/E3
CBL-E1-CC3/BNCF
15.12.8 Specifications
Table 15-75 lists specifications of the OPCOM3500E-3DS3/E3.
Table 15-75 Specifications of the OPCOM3500E-3DS3/E3
Parameter
Value
Dimensions
25 mm (width) × 232 mm (depth) × 240 mm (height)
Weight
< 0.45 kg
Max. power consumption
10 W
