iTN2100 (P100R002) Hardware Description
13 EOP cards
Raisecom Technology Co., Ltd.
83
13.1.3 Interfaces
Interface types
There are 2 interfaces on the OPCOM3500E-EOPFE panel, as listed in Table 13-1.
Table 13-1 Interfaces on the OPCOM3500E-EOPFE panel
Interface
Type
Description
–
MiniUSB
Debugging interface
FE
RJ45
Used for transmitting 1-way 100 Mbit/s Ethernet services.
Interface parameters
Table 13-2 lists parameters of interfaces 1–2 on the OPCOM3500E-EOPFE.
Table 13-2 Parameters of interfaces 1–2 on the OPCOM3500E-EOPFE
Parameter
Description
Connector type
RJ45
Interface speed
10/100 M bit/s/ auto-negotiation
Maximum supported frame length
1916 Bytes
Line order
Auto MDI/MDI-X
Duplex mode
Full duplex/half duplex/auto-negotiation
Flow control

Full duplex: IEEE 802.3x-based flow control

Half duplex: back-pressure flow control
13.1.4 LEDs
There are 4 LEDs on the OPCOM3500E-EOPFE panel, as listed in Table 13-3.
Table 13-3 LEDs on the OPCOM3500E-EOPFE panel
LED
Status
Description
PWR
Green
Power LED

Green: the power supply is normal.

Off: the power supply is abnormal.
SYS
Green
System status LED

Green: the system is working improperly.

Off: the system is working improperly.

Blinking green: the system is working properly.
