Raisecom
iTN2100 (P100R002) Hardware Description
13 EOP cards
Raisecom Technology Co., Ltd.
87
13.2.3 Interfaces
Interface types
There are 4 interfaces on the OPCOM3500E-EOP3FE panel, as listed in Table 13-6.
Table 13-6 Interfaces on the OPCOM3500E-EOP3FE panel
Interface
Type
Description
–
MiniUSB
Debugging interface
1, 2
SFP optical interface

Service uplink interface

TX indicates sending and RX indicates receiving.
FE
RJ45
Used for transmitting 1-way 100 Mbit/s Ethernet
services.
Interface parameters
Table 13-7 lists parameters of the RJ45 interface on the OPCOM3500E-EOP3FE.
Table 13-7 Parameters of the RJ45 interface on the OPCOM3500E-EOP3FE
Parameter
Description
Connector type
RJ45
Interface speed
10/100 M bit/s or auto-negotiation
Maximum supported frame length
1916 Bytes
Line order
Auto MDI/MDI-X
Duplex mode
Full duplex/half duplex/auto-negotiation
Flow control

Full duplex: IEEE 802.3x-based flow control

Half duplex: back-pressure flow control
Table 13-8 lists parameters of interfaces 1–2 on the OPCOM3500E-EOP3FE.
Table 13-8 Parameters of interfaces 1–2 on the OPCOM3500E-EOP3FE
Parameter
Description
Connector type
SFP optical interface
Interface speed
100 Mbit/s
Duplex mode
Full duplex
Maximum supported frame length
1916 Bytes
Compliance standard
IEEE802.3u and IEEE802.3z
