iTN2100 (P100R002) Hardware Description
14 EOS cards
Raisecom Technology Co., Ltd.
117
14.1 OPCOM3500E-EOS-4FE
14.1.1 Appearance and functions
Appearance
Function
The OPCOM3500E-EOS-4FE is a 4-way electrical interface EOS tributary card on the
iTN2100.

Provide four 10/100 Mbit/s Ethernet electrical interfaces.

Support assignment of four ways of Ethernet services with bandwidth of N×VC12 and
N×VC3 and then transmit them to the SDH network.

Support two Ethernet encapsulation modes: GFP and LAPS.

Support LCAS.

Support 2000 Bytes Ethernet frame length at most.

Support online software upgrade for local devices.

Support complete alarms.

Support statistics of sent frames, received frames, and error packages of each VCG.

Support hot swapping.
14.1.2 Slots
The OPCOM3500E-EOS-4FE can be plugged into slots 1–5 and 8–12 on the iTN2100.
