iTN2100 (P100R002) Hardware Description
8 Ethernet aggregation card
Raisecom Technology Co., Ltd.
48
Table 8-3 LEDs on the iTN2100-NTU-4GF
LED
Status
Description
PWR
Green
Power LED

Green: the power supply is normal.

Off: the power supply is abnormal.
SYS
Green
System status LED

Green: the system is working improperly.

Off: the system is working improperly.

Blinking green: the system is working properly.
ACT
Green
Primary/Slave LED

Green: the card is primary.

Off: the card is slave.
1000M
(1–4)
Green
SFP optical interface 1000 Mbit/s LED

Green: the Ethernet rate is 1000 Mbit/s.

Off: the Ethernet rate is 100 Mbit/s or the connection fails.
LNK/ACT
(1–4)
Green
SFP optical interface working LED

Green: the SFP optical interface is properly connected.

Off: the SFP optical interface is improperly connected or
disconnected.

Blinking green: the SFP optical interface is receiving or
sending data.
8.1.5 Specifications
Table 8-4 lists specifications of the iTN2100-NTU-4GF.
Table 8-4 Specifications of the iTN2100-NTU-4GF
Parameter
Value
Dimensions
25 mm (width) × 232 mm (depth) × 240 mm (height)
Weight
0.52 kg
Max. power consumption
26 W
