Raisecom iTN2100 User Manual

Raisecom
iTN2100 (P100R002) Hardware Description
4 Power supplies
Raisecom Technology Co., Ltd.
21
LED
Status
Description
Cri
Red
Input voltage hierarchical alarm LED

Red: the deviation between the input voltage and the centered
voltage is within range 3.

Off: the deviation between the input voltage and the centered
voltage is beyond range 3.

You can set range 1, range 2, and range 3 but they must be between -100 V
and -240 V.

If input voltage hierarchical alarm LED is yellow or red, the input voltage is
within the allowed range.

If the alarm LED is yellow or red, the power supply is communicating with the
back plane and reporting power alarm status.
4.3.5 Specifications
Table 4-9 lists specifications of the SUB-PWRM-AC.
Table 4-9 Specifications of the SUB-PWRM-AC
Parameter
Value
Dimensions
38.5 mm (width) × 224 mm (depth) × 240 mm (height)
Weight
1.1 kg
Zero-load power
consumption
10 W
Rated power consumption
600 W
Table 4-10 lists input parameters of the SUB-PWRM-AC.
Table 4-10 Input parameters of the SUB-PWRM-AC
Parameter
Value
Nominal input voltage range
100–240 V
Rated input voltage
110 V/220 V
AC input frequency
47–63 Hz
Power consumption factor
0.95
Integrated equipment
efficiency
110 V input (full load)
80%
220 V input (full load)
80%
