iTN2100 (P100R002) Hardware Description
14 EOS cards
Raisecom Technology Co., Ltd.
128
14.4.3 Interfaces
Interface types
There is only one interface on the OPCOM3500E-8EOS-FE panel, as listed in Table 14-17.
Table 14-17 Interface on the OPCOM3500E-8EOS-FE panel
Interface
Type
Description
–
RJ45
Service downlink interface
Interface parameters
Table 14-18 lists parameters of the RJ45 interface on the OPCOM3500E-8EOS-FE.
Table 14-18 Parameters of the RJ45 interface on the OPCOM3500E-8EOS-FE
Parameter
Description
Connector type
RJ45
Interface rate
10/100 Mbit/s or auto-negotiation
Duplex mode
Full duplex/half duplex/auto-negotiation
Maximum supported frame length
1632 Bytes
Flow control

Full duplex: IEEE 802.3x-based flow control

Half duplex: back-pressure flow control
Line order
Auto MDI/MDIX
14.4.4 LEDs
Table 14-19 lists LEDs on the OPCOM3500E-8EOS-FE panel.
Table 14-19 LEDs on the OPCOM3500E-8EOS-FE panel
Interface
Status
Description
PWR
Green
Power LED

Green: the power supply is normal.

Off: the power supply is abnormal.
SYS
Green
System status LED

Green: the system is working improperly.

Off: the system is working improperly.

Blinking green: the system is working properly.
