iTN2100 (P100R002) Hardware Description
7 SDH tributary cards
Raisecom Technology Co., Ltd.
37
7.1.3 Interfaces
Interface types
There are two interfaces on the OPCOM3500E-STM1-S panel, as listed in Table 7-1 and
Table 7-2.
Table 7-1 Interfaces on the OPCOM3500E-STM1-S (Versions A and B)
Interface
Type
Description
A, B
1×9 optical interface

Service uplink interface

TX indicates sending and RX indicates receiving.
Table 7-2 Interfaces on the OPCOM3500E-STM1-S (Version C)
Interface
Type
Description
1, 2
SFP optical interface

Service uplink interface

TX indicates sending and RX indicates receiving.
Interface parameters
Table 7-3 lists parameters of interfaces A and B on the OPCOM3500E-STM1-S (Versions A
and B).
Table 7-3 Parameters of interfaces A and B on the OPCOM3500E-STM1-S (Versions A and B)
Parameter
Description
Optical module type
1×9 optical module
Interface rate
STM-1
Line code
NRZ
Multiplexing structure
Comply with ITU-T G.707 recommendations.
Jitter
Comply with ITU-T G.783 and ITU-T G.825
recommendations.
Optical interface parameters
Comply with ITU-T G.957 recommendations.
Table 7-4 lists parameters of interfaces 1 and 2 on the OPCOM3500E-STM1-S (Version C).
Table 7-4 Parameters of interfaces 1 and 2 on the OPCOM3500E-STM1-S (Version C)
Parameter
Description
Optical module type
SFP optical module
Interface rate
STM-1
