Raisecom
iTN2100 (P100R002) Hardware Description
4 Power supplies
Raisecom Technology Co., Ltd.
18
Table 4-4 Specifications of the SUB-PWRM-DC
Parameter
Value
Dimensions
38.5 mm (width) × 224 mm (depth) × 240 mm (height)
Weight
1.05 kg
Zero-load power consumption
5 W
Rated power consumption
300 W
Table 4-5 lists input parameters of the SUB-PWRM-DC.
Table 4-5 Input parameters of the SUB-PWRM-DC
Parameter
Value
Remark
Rated input voltage
-48 V
–
Input voltage range
-36 V to -72 V
Under full load
Zero-load power
consumption
5 W
Under rated input voltage
Table 4-6 lists protection function parameters of the SUB-PWRM-DC.
Table 4-6 Protection function parameters of the SUB-PWRM-DC
Parameter
Value
Input undervoltage protection
34 V
Input overvoltage protection
90 V
Output overvoltage protection
6 V
Output current limit protection
72 A
