21.5.2 Appearance
Figure 21-10 shows the European standard AC cable.
Figure 21-10 European standard AC cable
Figure 21-11 shows the American standard AC cable.
Figure 21-11 American standard AC cable
21.5.3 Technical specifications
Table 21-7 lists specifications of the European standard AC power cable.
Table 21-7 Specifications of the European standard AC power cable
Parameter
Description
Name
French mode receptacle-10A/250V-1.5m/RoHS
Connector
French mode three-plug, IEC60320-C13 receptacle
Type
Copper core multi-strand power supply cable 18AWG
Length
1.5 m
Table 21-8 lists specifications of the American standard AC power cable.
Table 21-8 Specifications of the American standard AC power cable
Parameter
Description
Name
American standard three-plug-10A/250V-1.5m/RoHS
Connector
American standard three-plug connector NEMA5-15, IEC60320-C13
receptacle
Type
Copper core multi-strand power supply cable 18AWG
Length
1.5 m
