Raisecom iTN2100 - Alarms; Table 15-56 Configurations of DIP Switch SW7 on the OPCOM3500 E-120 H× 4 (Version B)

Raisecom
iTN2100 (P100R002) Hardware Description
15 PDH and RCMS cards
Raisecom Technology Co., Ltd.
179
SW7
Function
Status
Description
DIP bit
ALS on the optical
interface.
OFF
Disable ALS.
Bit2–Bit4
Reserved
–
–
By default, SW7 is all OFF. Namely, ALS is disabled by default.
Version B
The OPCOM3500E-120H×4 (Version B) has a DIP switch: SW7, as listed in Table 15-56.
Table 15-56 Configurations of DIP switch SW7 on the OPCOM3500E-120H×4 (Version B)
SW7
Function
Status
Description
DIP bit
Bit1
Enable or
disable ALS.
ON
Enable ALS.
OFF
Disable ALS.
Bit2
Reserved
Bit3
Bit4
Enable or
disable ISP
upgrade.
ON
Enable ISP upgrade.
OFF
Disable ISP upgrade.
By default, SW7 is all OFF.
15.10.6 Alarms
Version A
Table 15-57 lists alarms of the OPCOM3500E-120H×4 (version A).
