iTN2100 (P100R002) Hardware Description
12 TDMoP card
Raisecom Technology Co., Ltd.
79
12.1.3 Interfaces
Interface types
There are 17 interfaces on the iTN2100-CES-16E1T1-BL panel, as listed in Table 12-1.
Table 12-1 Interfaces on the iTN2100-CES-16E1T1-BL panel
Interface
Type
Description
–
MiniUSB
Debugging interface
1–16
RJ45
E1 balanced interface. Each RJ45 interface provides 2-way E1
services.
Interface parameters
Table 12-2 lists parameters of interfaces 1–16 on the iTN2100-CES-16E1T1-BL.
Table 12-2 Parameters of interfaces 1–16 on the iTN2100-CES-16E1T1-BL
Parameter
Description
Connector type
RJ45
Interface impedance
120Ω balanced interface
Interface speed
2.048 Mbit/s
Coding type
HDB3
Supported frame format
Unframed, PCM31, PCM31C, PCM30, and PCM30C
Frame structure
Comply with ITU-TG.703/ITU-TG.704 recommendations.
Clock
Comply with ITU-TG.823 recommendations.
Jitter
Comply with ITU-TG.823 recommendations.
Electrical feature
Comply with ITU-TG.703 recommendations and support
short distance.
Wander feature
Comply with ITU-TG.823 recommendations.
12.1.4 LEDs
There are 18 LEDs on the iTN2100-CES-16E1T1-BL panel, as listed in Table 12-3.
