Raisecom iTN2100 - DIP Switches; Table 15-24 Configurations of DIP Switch SW2 on the OPCOM3500 E-120 EOS× 4; Table 15-25 Configurations of DIP Switch SW3 on the OPCOM3500 E-120 EOS× 4

Raisecom
iTN2100 (P100R002) Hardware Description
15 PDH and RCMS cards
Raisecom Technology Co., Ltd.
156
15.5.5 DIP switches
Table 15-24, Table 15-25, and Table 15-26 list configurations of DIP switches on the
OPCOM3500E-120EOS×4.
Table 15-24 Configurations of DIP switch SW2 on the OPCOM3500E-120EOS×4
DIP
switch
Function
Status
Description
Bit1
Bit2
Bit3
Bit4
Optical interface
device
SW2
Set the type
of the
optical
interface
device.
ON
ON
ON
ON
M
ON
ON
ON
OFF
S1
ON
ON
OFF
ON
S2
ON
ON
OFF
OFF
S3
ON
OFF
ON
ON
SS13
ON
OFF
ON
OFF
SS15
ON
OFF
OFF
ON
SS23
ON
OFF
OFF
OFF
SS25
SW2 is properly configured before the card leaves the factory. Do not configure it if
not needed.
Table 15-25 Configurations of DIP switch SW3 on the OPCOM3500E-120EOS×4
SW3
Function
Status
Description
DIP bit
Bit1
Enable or
disable ALS
ON
Enable ALS.
OFF
Disable ALS.
Bit2
Reserved
Bit3
Bit4
By default, SW3 is all OFF. Namely, ALS is disabled by default.
