iTN2100 (P100R002) Hardware Description
13 EOP cards
Raisecom Technology Co., Ltd.
91
13.3.3 Interfaces
Interface types
There are 9 interfaces on the OPCOM3500E-EOP8FX panel, as listed in Table 13-12.
Table 13-12 Interfaces on the OPCOM3500E-EOP8FX panel
Interface
Type
Description
–
MiniUSB
Debugging interface
1–8
SFP optical interface
Service downlink interface
Interface parameters
Table 13-13 lists parameters of interfaces 1–8 on the OPCOM3500E-EOP8FX.
Table 13-13 Parameters of interfaces 1–8 on the OPCOM3500E-EOP8FX
Parameter
Description
Connector type
SFP (LC/PC)
Line code
4B/5B block coding and NRZI line coding
Interface speed
100 Mbit/s
Interface specification
100Base-FX
Duplex mode
Full duplex
Flow control
IEEE802.3x-based flow control in full duplex mode
Compliance standard
IEEE 802.3u
13.3.4 LEDs
There are 10 LEDs on the OPCOM3500E-EOP8FX panel, as listed in Table 13-14
Table 13-14 LEDs on the OPCOM3500E-EOP8FX panel
LED
Status
Description
PWR
Green
Power LED

Green: the power supply is normal.

Off: the power supply is abnormal.
SYS
Green
System status LED

Green: the system is working improperly.

Off: the system is working improperly.

Blinking green: the system is working properly.
