20.3.3 Interfaces
There are 5 interfaces on the iTN2100-4SU-D panel, as listed in Table 20-19.
Table 20-19 Interfaces on the iTN2100-4SU-D panel
Interface
Type
Description
LINE
1×9 optical interface
(SC/PC)

Line-side interface, used for receive/send
multiplexed optical signals

TX indicates sending and RX indicates receiving.
1511
1×9 optical interface
(SC/PC)

Client-side interface, used for receive/send 1511
nm optical signals

TX indicates sending and RX indicates receiving.
1531
1×9 optical interface
(SC/PC)

Client-side interface, used for receive/send 1531
nm optical signals

TX indicates sending and RX indicates receiving.
1551
1×9 optical interface
(SC/PC)

Client-side interface, used for receive/send 1551
nm optical signals

TX indicates sending and RX indicates receiving.
1571
1×9 optical interface
(SC/PC)

Client-side interface, used for receive/send 1571
nm optical signals

TX indicates sending and RX indicates receiving.
20.3.4 LEDs
There are 2 LEDs on the iTN2100-4SU-D panel, as listed in Table 20-20.
Table 20-20 LEDs on the iTN2100-4SU-D panel
LED
Status
Description
PWR
Green
Power LED

Green: the power supply is normal.

Off: the power supply is abnormal.
SYS
Green
System status LED

Green: the system is working improperly.

Off: the system is working improperly.

Blinking green: the system is working properly.
20.3.5 Specifications
Table 20-21 lists specifications of the iTN2100-4SU-D.
Table 20-21 Specifications of the iTN2100-4SU-D
Parameter
Value
Dimensions
25 mm (width) × 232 mm (depth) × 240 mm (height)
Weight
0.44 kg
