iTN2100 (P100R002) Hardware Description
9 Ethernet switching card
Raisecom Technology Co., Ltd.
51
9.1.3 Interfaces
Interface types
There are seven interfaces on the iTN2100-PTU-4GE panel, as listed in Table 9-1.
Table 9-1 Interfaces on the iTN2100-PTU-4GE panel
Interface
Type
Description
–
MiniUSB
Debugging interface
1–4
SFP optical
interface

Service uplink interface

TX indicates sending and RX indicates receiving.
SYNC-RX
CC3 male connector
Reserved
SYNC-TX
CC3 male connector
Reserved
Interface parameters
Table 9-2 lists parameters of interfaces 1–4 on the iTN2100-PTU-4GE.
Table 9-2 Parameters of interfaces 1–4 on the iTN2100-PTU-4GE
Parameter
Description
Connector type
SFP (LC/PC)
Line code
8B/10B
Transmission rate
1.25 Gbit/s
Working mode
Full duplex
Maximum supported frame
length
1522–13312 Bytes, configurable
Supported frame format
Ethernet-II, Ethernet-SAP, and Ethernet-SNAP
Supported network protocol
IP
Compliance standard
IEEE 802.3
Supported optical modules

Interfaces 1 and 2: 1000BASE-X SFP and
1000BASE-T SFP

Interface 3 and 4: 1000BASE-X SFP, 1000BASE-T
SFP, and 10/100/1000BASE-T SFP
9.1.4 LEDs
There are 11 LEDs on the iTN2100-PTU-4GE, as listed in Table 9-3.
