iTN2100 (P100R002) Hardware Description
21 Cables
Raisecom Technology Co., Ltd.
268
Table 21-29 Specifications of the CBL-V35-HDB26M/M34F cable
Parameter
Description
Name
CBL-V35-HDB26M/M34F
Connector
HDB26 male connector, or M34 female connector
Type
9.5P+1+B+AL cable
21.12.5 CBL-V35-HDB26M/M34M
Appearance
Figure 21-27 shows the CBL-V35-HDB26M/M34M cable.
Figure 21-27 CBL-V35-HDB26M/M34M cable
Specifications
Table 21-30 lists specifications of the CBL-V35-HDB26M/M34M cable.
Table 21-30 Specifications of the CBL-V35-HDB26M/M34M cable
Parameter
Description
Name
CBL-V35-HDB26M/M34M
Connector
HDB26 male connector, or M34 male connector
Type
9.5P+1+B+AL cable
21.12.6 CBL-V35-HDB26M/DB25M
Appearance
Figure 21-28 shows the CBL-V35-HDB26M/DB25M cable.
