Table 20-7 Configurations on client-side interfaces of the iTN2100-Gb (A)
Recommended
configuration
USFP-Gb series SFP optical
modules
Recommended
Better jitter
performance
USFP-Gb series SFP optical
modules
Recommended
Better jitter
performance
1000BASE-X
Optical signals
USFP-Gb series SFP optical
modules
3R mode + manual +
1000BASE-X
Better jitter
performance
100BASE-X
Optical signals
USFP-Gb series SFP optical
modules
3R mode + manual +
100BASE-X
Better jitter
performance
1000BASE-T
Electrical
signals
USFP-GE series SFP
electrical modules
USFP-GE/AN series SFP
electrical modules
3R mode + manual +
1000BASE-T
Better jitter
performance
100BASE-T
Electrical
signals
USFP-GE/AN series SFP
electrical modules
USFP-FE/AN series SFP
electrical modules
3R mode + manual +
100BASE-T
Better jitter
performance
10BASE-T
Electrical
signals
USFP-GE/AN series SFP
electrical modules
USFP-FE/AN series SFP
electrical modules
Optical signals
with other
speeds
USFP-Gb series SFP optical
modules
In DIP switch column of Table 20-7, N refers to ON and F refers to OFF.
Configurations through the NView NNM system have higher priorities then the
ones configured through DIP switches. When no configuration is performed
through the NView NNM system, DIP switch configurations are valid. Otherwise,
configurations through the NView NNM system take effect.
The iTN2100-Gb cards must be used in pair. In addition, configurations on
related interfaces of the 2 card must be identical.
SFP electrical modules do not support failover and ALS.
For better transmission performance, we recommend using the 2R mode.
