Raisecom

iTN2100 (P100R002) Hardware Description

21 Cables

Raisecom Technology Co., Ltd.

267

Figure 21-25 CBL-V35-HDB26M/2M34M cable

Specifications

Table 21-28 lists specifications of the CBL-V35-HDB26M/2M34M cable.

Table 21-28 Specifications of the CBL-V35-HDB26M/2M34M cable

Parameter

Description

Name

CBL-V35-HDB26M/2M34M

Connector

HDB26 male connector, or M34 female connector

Type

9.5P+1+B+AL cable

21.12.4 CBL-V35-HDB26M/M34F

Appearance

Figure 21-26 shows the CBL-V35-HDB26M/M34F cable.

Figure 21-26 CBL-V35-HDB26M/M34F cable

Specifications

Table 21-29 lists specifications of the CBL-V35-HDB26M/M34F cable.
