Raisecom iTN2100 User Manual

Raisecom
iTN2100 (P100R002) Hardware Description
3 Fan
Raisecom Technology Co., Ltd.
10
Figure 3-1 Front panel of the FANS360
Figure 3-2 Rear panel of the iTN2100
3.3 LEDs
Table 3-1 lists LEDs on the front panel of the FANS360.
Table 3-1 LEDs on the front panel of the FANS360
LED
Status
Description
PWR
Green
Power LED

Green: the power supply is normal.

Off: the power supply is abnormal.
ALM
Red
Working status LED

Red: the fan is working improperly.

Off: the fan is working properly.
3.4 Specifications
Table 3-2 lists specifications of the FANS360.
Table 3-2 Specifications of the FANS360
Parameter
Value
Dimensions
440 mm (width) × 247 mm (depth) × 44 mm (height)
Weight
3.0 kg
Max. power consumption
28 W
Number of fans
3
Highest revolving speed
3250 r/min
