Raisecom

iTN2100 (P100R002) Hardware Description

21 Cables

Raisecom Technology Co., Ltd.

263

21.11.2 CBL-V24-HDB26M/4DB25F

Appearance

Figure 21-22 shows the CBL-V24-HDB26M/4DB25F cable.

Figure 21-22 CBL-V24-HDB26M/4DB25F cable

Specifications

Table 21-23 lists specifications of the CBL-V24-HDB26M/4DB25F cable.

Table 21-23 Specifications of the CBL-V24-HDB26M/4DB25F cable

Parameter

Description

Name

CBL-V24-HDB26M/4DB25F

Connector

HDB26 male connector, or DB25 female connector

Type

9-core data cable

21.11.3 CBL-V24-HDB26M/4DB25M

Appearance

Figure 21-23 shows the CBL-V24-HDB26M/4DB25M cable.
