iTN2100 (P100R002) Hardware Description
13 EOP cards
Raisecom Technology Co., Ltd.
101
13.6.3 Interfaces
Interface types
There are eight interfaces on the OPCOM3500E-EOP-FXE1×8 panel, as listed in Table 13-26.
Table 13-26 Interfaces on the OPCOM3500E-EOP-FXE1×8 panel
Interface
Type
Description
1–8
SFP optical interface
100Base-FX interface
Interface parameters
Table 13-27 lists parameters of the OPCOM3500E-EOP-FXE1×8.
Table 13-27 Parameters of the OPCOM3500E-EOP-FXE1×8
Parameter
Description
Connector type
SFP/LC
Interface rate
100 Mbit/s
Line code
4B/5B block code and NRZI Line code
Duplex mode
Full duplex
Flow control
IEEE 802.3x-based flow control in full duplex mode
Compliance standard
IEEE 802.3u
13.6.4 LEDs
There are eight LEDs on the OPCOM3500E-EOP-FXE1×8 panel, as listed in Table 13-28.
Table 13-28 LEDs on the OPCOM3500E-EOP-FXE1×8 panel
Interface
Status
Description
PWR
Green
Power LED

Green: the power supply is normal.

Off: the power supply is abnormal.
SYS
Green
System status LED

Green: the system is working improperly.

Off: the system is working improperly.

Blinking green: the system is working properly.
