Raisecom iTN2100 User Manual

Raisecom
iTN2100 (P100R002) Hardware Description
13 EOP cards
Raisecom Technology Co., Ltd.
115
Alarm
Cause
Level
TU-AIS

Services are improperly configured.

The channel of the peer device fails.

Higher order path alarms, such as R-LOS, trigger the
alarm.

The cross connection card fails.
Minor
TU-LOP

The interface between the tributary card and the cross
connection card fails.

Services are improperly configured.
Critical
LP-TIM

The low order path trace identifiers of the local
device and the peer device are inconsistent.

Services are improperly configured.
Critical
E1 AIS alarm
E1 signals are composed of "1" only, because
transmission fails or the peer device outputs AIS
signals.
Critical
E1 LOF alarm
The output data of uplink devices is incorrect, because
services are improperly configured or hardware fails.
Critical
E1 CRC alarm
Data error occurs in transmission.
Critical
E1 remote loopback
alarm
The remote device managed by the card generates
loopback alarms.
Critical
13.9.7 Specifications
Table 13-47 lists specifications of the iTN2100-EOT-GESTM4.
Table 13-47 Specifications of the iTN2100-EOT-GESTM4
Parameter
Value
Dimensions
25 mm (width) × 232 mm (depth) × 240 mm (height)
Weight
< 0.45 kg
Max. power consumption
30 W
