iTN2100 (P100R002) Hardware Description
10 Ethernet access cards
Raisecom Technology Co., Ltd.
59
10.2.2 Slots
The iTN2100-8FX can be plugged into slots 1–5 and 8–12 on the iTN2100.
10.2.3 Interface
Interface type
There are nine interfaces on the iTN2100-8FX panel, as listed in Table 10-6.
Table 10-6 Interfaces on the iTN2100-8FX panel
Interface
Type
Description
–
MiniUSB
Debugging interface
1–8
SFP optical interface
Each optical interface can transmit one way of
Ethernet optical signals.
Interface parameters
Table 10-7 lists parameters of interfaces 1–8 of the iTN2100-8FX.
Table 10-7 Parameters of interfaces 1–8 of the iTN2100-8FX
Parameter
Description
Connector type
SFP optical interface
Interface rate
100 Mbit/s
Duplex mode
Full duplex
Compliance standard
IEEE802.3 and IEEE802.3u
Table 10-8 lists transmission parameters of optical interfaces 1–8 of the iTN2100-8FX.
Table 10-8 Transmission parameters of optical interfaces 1–8 of the iTN2100-8FX
Optical
interface
Connector
Working
wavelength
(nm)
Transmit
power
(dB)
Receiver
sensitivity
(dBm)
Light
saturation
(dB)
Transmission
distance (km)
Optical
loss
(dB/km)
S1
DSC/PC
1310
-15 to -8
-34
-8
0–25
0.5
S2
DSC/PC
1310
-5 to 0
-34
-8
10–60
0.5
S3
DSC/PC
1550/DFB
-5 to 0
-36
-10
15–120
0.25
SS13
SC/PC
Tx: 1310
Rx: 1550
-12 to -3
-30
-8
0–25
0.5
