iTN2100 (P100R002) Hardware Description
13 EOP cards
Raisecom Technology Co., Ltd.
110
Interface
Status
Description
LNK/ACT
(1–6)
Green
Link working LED

Green: the link interface is properly connected.

Off: the link interface improperly connected or disconnected.

Blinking green: the link interface is receiving or sending data.
13.8.5 Alarms
Table 13-40 lists alarms of the OPCOM3500E-HT-6FE24E1.
Table 13-40 Alarms of the OPCOM3500E-HT-6FE24E1
Alarm
Cause
Level
E1 AIS alarm
E1 signals are composed of "1" only,
because transmission fails or the peer
device outputs AIS signals.
Critical
E1 LOF alarm
The output data of uplink devices is
incorrect, because services are improperly
configured or hardware fails.
Critical
E1 CRC alarm
Data error occurs in transmission.
Critical
E1 GID ERROR alarm
Reverse duplexing is improperly
configured.
Critical
E1 remote loopback alarm
The remote device managed by the card
generates loopback alarms.
Critical
Ethernet interface link down
alarms
Alarms are generated due to Ethernet
interface link failure.
Critical
13.8.6 Specifications
Table 13-41 lists specifications of the OPCOM3500E-HT-6FE24E1.
Table 13-41 Specifications of the OPCOM3500E-HT-6FE24E1
Parameter
Value
Dimensions
25 mm (width) × 232 mm (depth) × 240 mm (height)
Weight
0.45 kg
Max. power consumption
12 W
