iTN2100 (P100R002) Hardware Description
10 Ethernet access cards
Raisecom Technology Co., Ltd.
70
10.5.3 Interfaces
Interface types
There are eight interfaces on the OPCOM3500E-8FX panel, as listed in Table 10-21.
Table 10-21 Interfaces on the OPCOM3500E-8FX panel.
Interface
Parameter
Description
1–8
SFP optical interface
Each interface transmits one way of Ethernet
optical signals.
–
MiniUSB
Debugging interface
Interface parameters
Table 10-22 lists parameters of interfaces 1–8 on the OPCOM3500E-8FX.
Table 10-22 Parameters of interfaces 1–8 on the OPCOM3500E-8FX
Parameter
Description
Connector type
SFP optical interface
Interface rate
100 Mbit/s
Maximum supported frame length
1632 Bytes
Flow control
IEEE 802.3x-based flow control in full duplex
mode
10.5.4 LEDs
There are 10 LEDs on the OPCOM3500E-8FX panel, as listed in Table 10-23.
Table 10-23 LEDs on the OPCOM3500E-8FX panel
Interface
Status
Description
PWR
Green
Power LED

Green: the power supply is normal.

Off: the power supply is abnormal.
SYS
Green
System status LED

Green: the system is working improperly.

Off: the system is working improperly.

Blinking green: the system is working properly.
