iTN2100 (P100R002) Hardware Description
8 Ethernet aggregation card
Raisecom Technology Co., Ltd.
47
8.1.3 Interfaces
Interface types
There are seven interfaces on the iTN2100-NTU-4GF panel, as listed inTable 8-1.
Table 8-1 Interfaces on the iTN2100-NTU-4GF panel
Interface
Type
Description
–
MiniUSB
Debugging interface
1–4
SFP optical interface
Service uplink interface
SYNC-RX
CC3 male connector
BITS clock input
SYNC-TX
CC3 male connector
BITS clock output
Interface parameters
Table 8-2 lists parameters of interfaces 1–4 on the iTN2100-NTU-4GF.
Table 8-2 Parameters of interfaces 1–4 on the iTN2100-NTU-4GF
Parameter
Description
Connector type
SFP (LC/PC)
Line code
8B/10B
Transmission rate
1.25 Gbit/s
Working mode
Full duplex
Maximum supported frame length
13 KB
Supported frame format
Ethernet-II, Ethernet-SAP, and Ethernet-SNAP
Supported network protocol
IP
Compliance standard
IEEE 802.3
Supported optical modules
100BASE-FX SFP, 1000BASE-X SFP,
1000BASE-T SFP, and 10/100/1000BASE-T SFP
8.1.4 LEDs
There are 11 LEDs on the iTN2100-NTU-4GF, as listed in Table 8-3.
