5 NMS card
Raisecom Technology Co., Ltd.
25
5.1.3 Interfaces
Interface types
There are four interfaces on the iTN2100-NMS panel, as listed in Table 5-1.
Table 5-1 Interfaces on the iTN2100-NMS panel
Print
Connector type
Description
SNMP
RJ45
NMS interface
NM-EXT
RJ45
Extended NMS interface
CONSOLE
RJ45
Console interface
RS232
RJ45
User byte interface
Interface parameters
The SNMP interface and the NM-EXT interface have the same parameters, as listed in Table
5-2.
Table 5-2 Parameters of the SNMP interface on the iTN2100-NMS card
Parameter
Description
Connector type
RJ45
Interface rate
10/100 Mbit/s or auto-negotiation
Duplex mode
Full duplex
Line order
Auto MDI/MDIX
Standard
IEEE 802.3
Table 5-3 lists parameters of the CONSOLE interface on the iTN2100-NMS.
Table 5-3 Parameters of the CONSOLE interface on the iTN2100-NMS
Parameter
Description
Connector type
RJ45
Interface rate
9600 bit/s
Standard
RS232
