iTN2100 (P100R002) Hardware Description
15 PDH and RCMS cards
Raisecom Technology Co., Ltd.
143
Table 15-11 Alarms of the OPCOM3500E-32E1/32E1-BL
Alarm
Cause
Level
E1 LOS alarm

Attenuation of received signals is over great.

The peer sender fails.

The fiber head is unclean or the connector is
improperly connected.

The local receiver fails.
Critical
E1 AIS alarm

Timeslot of the backplane of VC12 corresponding to
the local E1 is faulty or improperly configured.

The E1 channel of the remote PDH device is faulty or
improperly configured.
Minor
15.2.7 Cables
Table 15-12 lists cables of the OPCOM3500E-32E1/32E1-BL.
Table 15-12 Cables of the OPCOM3500E-32E1/32E1-BL
Card
Cable
OPCOM3500E-32E1

CBL-E1-SCSI100M(40)/32BNCF

CBL-E1-SCSI100M(40)/32BNCM
OPCOM3500E-32E1-BL
Non-balanced
interface
Balanced interface
CBL-E1-SCSI100M (40)/16RJ45
15.2.8 Specifications
Table 15-13 lists specifications of the OPCOM3500E-32E1/32E1-BL.
Table 15-13 Specifications of the OPCOM3500E-32E1/32E1-BL
Parameter
Value
Dimensions
25 mm (width) × 232 mm (depth) × 240 mm (height)
Weight
< 0.45 kg
Max. power consumption
3 W
